In the era of smart cars, cockpit design is changing from functional stacking to experience priority, and the importance of HMI (human-computer interaction interface) design is becoming more and more prominent. This article will explore how to optimize the information layout of the intelligent cockpit through the principle of “vision is above, operation is below” to improve the safety and convenience of driving.
In today’s rapid iteration of smart cars, cockpit design is undergoing a shift in thinking from “function stacking” to “experience first”. As a key area of human-computer interaction, the design of intelligent cockpit has a pivotal impact on driving safety, comfort and convenience.
The “vision is above, operation is below” is mainly reflected in the driver’s attention allocation and operating habits during the driving process to ensure driving safety and information acquisition efficiency, and further refine the reasonable distribution of information hierarchy and interaction area.
At the beginning, I put forward the principle of “vision is above, operation is below” in the process of participating in the formulation of the “Interactive Guidance Manual” by Baidu Internet of Vehicles. This principle aims to optimize the driver’s visual and operational experience during driving, reduce distraction caused by inconvenient information acquisition and operation, and improve driving safety. After a period of internal practice verification and continuous improvement, on May 23, 2022, through the article “Everyone is a Product Manager” Get started quickly! Key points of automotive HMI design” was officially released.
1. Physiological and psychological basis of vision
From the perspective of physiology and psychology, the visual system of the human eye has a unique structure and function, the foveal is a small area in the center of the retina, this part only has cones, and light can directly reach the cones, which gives the central field of vision extremely high visual acuity and color resolution, allowing it to process key information quickly and clearly. This physiological characteristic determines that when people observe things, they will instinctively focus their attention on the central area of their field of vision. According to the theory of perception in applied psychology, the human visual system prioritizes information from the center of the visual field and uses peripheral vision to perceive non-critical information to maintain the overall perception of the surrounding environment. Moreover, based on the theory of attention distribution, the driver’s attention resources during driving are limited, and placing the core driving information in the center of the visual cone can allow the driver to quickly capture key content, reduce distraction, and improve driving safety.
